DC Fast Charger IP55 160kW
Model : GEVCS160DC
EV Charger Station is designed for fast, safe, and smart charging, our EV stations support residential, commercial, and public use with scalable power options. Featuring rugged durability and energy-efficient technology, they ensure reliable performance in all conditions.
-
Key Benefits:
-
High-speed charging with intelligent load management
-
Weatherproof & vandal-resistant designs
-
Seamless integration with renewable energy systems
- Ideal for: Shopping malls, highways, workplaces & smart cities
-
Application
New energy vehicle store, Taxi, Bus, Public fast charging station, Big truck, Community building, Enterprises and institutions, Urban complex etc.
| Parameter | 160kW Model |
| Output Power Specification | DC 160kW |
| Number of Guns | Dual-gun |
| AC Input Voltage | 3-phase AC 380V (A/B/C+N+PE) ±15% |
| AC Input Current | 242A |
| AC Power Frequency | 50±5Hz |
| Input Power Factor | ≥0.99 |
| Full-load Charging Efficiency | ≥95% |
| DC Output Voltage Range | 200V–750V / 200V–1000V (optional) |
| Constant Power Range | 400V–750V / 300V–1000V |
| Max Output Current per Gun | 250A |
| Max Total Output Current | 400A (dual-gun) / 500A (dual-gun) |
| Communication | 4G / Ethernet / Standalone |
| Display | 10.1″ high-brightness capacitive touchscreen |
| Charging Methods | QR code / RFID card / VIN code / password |
| Operating Temperature | -30°C to +50°C |
| Relative Humidity | 0–95% (non-condensing) |
| Cooling Method | Forced air cooling, dustproof |
| Noise Level | <65dB |
| BMS Auxiliary Power | 12V/24V switchable |
| Protection Rating | IP55 |
| Standby Power Consumption | <40W |
| Charging Interface Standard | GB/T 20234.3 |
| Dimensions (H×W×D) | 1705×750×568mm |
| Base Dimensions | 650×532mm |
